Range Data
Part Number |
Anchor Hole Size
(d0) mm
|
Anchor Plug Length
(Lplug) mm
|
Max Fixture Thickness
(tfix) mm
|
Min Hole Depth
(h1) mm
|
---|---|---|---|---|
NHS05030SS | 5 | 30 | 5 | 30 |
NHS06040SS | 6 | 40 | 10 | 35 |
NHS06060SS | 6 | 60 | 30 | 35 |
NHS06070SS | 6 | 70 | 40 | 35 |
NHS08060SS | 8 | 60 | 20 | 45 |
NHS08080SS | 8 | 80 | 40 | 45 |
NHS08100SS | 8 | 100 | 60 | 45 |
